Fru Configurations; Internal Storage Configurations; Disk Tray Positions - HP Visualize c100 Service Handbook

Configuration
FRU Configurations
FRU Configurations
This section provides information for setting up or
changing the configuration of the system Field
Replaceable Units (FRUs).
Internal Storage Configurations
Each storage device is restricted as to where in the
storage tray it may be installed. Before installing a
storage device, use Figure 7 and Table 8 to determine
which disk tray position is correct for your device.
Figure 7 shows the storage device positions in the disk
tray. Table 8 lists what devices are supported in the
different disk tray positions. The numbers in the left
column of Table 7 refer to the position numbers in
Figure 7.
Figure 7

Disk Tray Positions
