Product Information
System Unit Rear Panel Connectors

Keyboard and Mouse Connectors

PS/2 Keyboard and Mouse Connectors

The PS/2 connectors provide an interface for the key-
board, mouse, and a variety of other pointing devices,
such as trackballs, to the system. Consult the docu-
mentation that accompanies each input device for
specific information concerning its use.

ITF Keyboard Connector

On the C100/C110/C160/C180 systems, the HP HIL
connector provides an interface for the ITF Keyboard
to the system. Consult the documentation that accom-
panies each input device for specific information con-
cerning its use. On the C200 systems, ITF is available
through the PS/2 connector using a special adaptor and
by setting four jumpers on the leg I/O board.

HP Parallel I/O Connector

The 25-pin HP Parallel I/O interface uses Centronics
interface protocols to support peripheral devices such
as printers and plotters. Consult the documentation
that accompanies each peripheral device for specific
information concerning its use.

802.3 Network Connectors

The C Class workstations have built-in ThickNet
LAN-AUI and LAN-TP (Twisted Pair) connectors for
the 802.3 (ETHERNET) network. Connections to
ThinLAN networks require an external transceiver.
The workstation automatically selects the correct net-
work setting.
19
