connector (C200 new, C240, C360 only)
Two Serial Interfaces RS232C, 9-pin male
One Parallel Interface, Centronics, BUSY hand-
shake, 25-pin female
16 Bit Audio Line-in and Line-out connectors
Two PS/2 ports
One HP-HIL connector
• EISA/GSC: 4 slots total
C100/110
Slot1 - EISA/GSC (no GSC graphics support)
Slot 2 - EISA/GSC (no GSC graphics support)
Slot 3 - EISA/GSC
Slot 4 - GSC
C160L
Slot 1 - EISA/ GSC
Slot 2 - EISA/GSC
Slot 3 - EISA/PCI (32-bit, 3.3V)
Slot 4 - PCI (32-bit, 3.3V)
C160/180
Slot 1 - EISA/GSC
Slot 2 - EISA/GSC
Slot 3 - EISA/GSC/PCI (32-bit, 3.3V)
Slot 4 - GSC/PCI (32-bit, 3.3V)
C200/C240/C360
Slot 1 - EISA-Optional/GSC/PCI (32-bit, 5V)
Slot 2 - GSC/PCI (64-bit, 3.3V)
Slot 3 - GSC/PCI (32-bit, 5V)
Slot 4 - GSC/PCI (64-bit, 3.3V)
• Keyboards:
PS/2 Keyboard (mouse)
or
ITF Keyboard (also known as HP HIL)
(HP HIL mouse) (C100/110 only)
(also available via hidden HIL using PS/2
connection (C200 only))
Product Information
Product Description
5
