Field Replaceable Units
FRU Removal and Replacement
Figure 46
Removing the EISA Slider and Retainer
3 Remove the screw from the EISA retainer and remove it,
4 If you are removing a PCI, EISA, or GSC board grasp it
134
EISA Retainer
as shown in Figure 46.
by the edge with both hands and pull it straight out.
Perform Steps 4 through 1 in reverse order to replace the
board.
EISA Slider
