HP Visualize c100 Service Handbook page 186

Diagrams
System Power
Table 16 CPU Board Power Pinouts for J10
Pin
Row D
Number
1 GND
2 FAMILY
3 P12V
4 P12V
5 VDD
6 VDD
7 VDD
8 VDD
9 VDD
10 VDL
11 VDD
12 VDL
13 VDD
14 VDD
15 VDL
16 VDD
17 VDL
18 VDD
19 VDD
20 VDL
21 VDD
22 VDL
23 VDD
24 VDD
25 VDL
26 VDD
27 VDL
28 VDD
29 VDD
30 VDL
31 VDD
158
Row C Row B
GND PWR_RST_CPU_L
N12V
GND_SENSE
VDD_SENSE GSC_ASYNC
VDL-SENSE GSC_HI_SPEED
GND
IO_ID(1) BP_ID(1)
IO_ID(1) BP_ID(0)
GND SPARE1
N3P2V
P2V PWR_RESET_L
STRT_PWROFF_L EPR_CS2_L
EPR_D(7)
GND EPR_D(5)
EPR_D(3) EPR_D(2)
EPR_D(0) EPR_A(2)
EPR_A(1) EPR_A(0)
GND
EPR_OE_L FP_DATA
LCD_EN LCD_RS
LCD_D(0) LCD_D(2)
GND
LCD_D(3) LCD_D(4)
LCD_D(5)
LCD_D(6)
LCD_D(7)
GND GSC_L
GSC0_DRR_L GSC0_PEND_L
GSC0_RETRY_L GSC0_AD(0)
GSC0_AD(1)
GND GSC0_AD(3)
Row A
GND
GND SPARE5
GND SPARE4
GND
SPARE3
GND SPARE2
GND
LASI_EBG_L
LASI_EBG_L
GND TOC_L
GND
EPR_CS1_L
GND EPR_D(6)
EPR_D(4)
EPR_D(1)
GND
EPR_LEN
GND EPR_WR_L
FP_CLK
LCD_D(1)
GND
GND MGSC0_RESET_L
GND
GND MGSC0_SYNC_L
GND MGSC0_SYNC_H
GND GND
GSC0_XQ_L
GSC0_PACK_L
GND
GND GSC0_AD(2)
GSC0_AD(4)
