HP Visualize c100 Service Handbook page 106

Troubleshooting
Selftest Failures
chassis codes "8C0y".
They are preceded by "TEST ".
Code Name
0001 DINO_IAR0_ONES_TEST
0002 DINO_IAR0_ZERO_TEST
0003 DINO_IAR1_ONES_TEST
0004 DINO_IAR1_ZERO_TEST
0005 DINO_IC0_ONES_TEST
0006 DINO_ICR_ZERO_TEST
0007 DINO_IO_CONTROL_INIT
ister
0008 DINO_IO_FBB_EN_INIT
ter
0009 DINO_IIO_ADDR_EN_ZERO_TEST ars io_addr_en reg-
ister
000A DINO_CONFIG_ADDR_ONES_TEST ars config_addr reg-
ister
000B DINO_CONFIG_ADDR_ZERO_TEST ars config_addr reg-
ister
000C DINO_GMAST_ONES_TEST
000D DINO_GMAST_ZERO_TEST
000E DINO_PAMR_INIT
000F DINO_PAPR_ONES_INIT
0010 DINO_PAPR_ZERO_INIT
0011 DINO_DAMODE_ONES_TEST
0012 DINO_DAMODE_ZERO_TEST
0013 DINO_PCICMD_INIT
0014 DINO_MLTIM_INIT
0015 DINO_BRDG_FEAT_INIT
ister
0016 DINO_PCIROR_INIT
0017 DINO_PCIWOR_INIT
0018 DINO_TLTIM_INIT
* = Unexpected interrupts that should never occur in PDC
code.
Code Name
1000 UNEXPECTED_INTERRUPT
during PDC execution
1x01 UNEXPECTED_INTERRUPT
1x02 UNEXPECTED_INTERRUPT
(unused)*
1x03 UNEXPECTED_INTERRUPT
Trap*
1x04 UNEXPECTED_INTERRUPT
1x05 UNEXPECTED_INTERRUPT
1x06 UNEXPECTED_INTERRUPT
1x07 UNEXPECTED_INTERRUPT
tection trap*
1x08 UNEXPECTED_INTERRUPT
trap
1x09 UNEXPECTED_INTERRUPT
trap
1x0A UNEXPECTED_INTERRUPT
tion trap*
1x0B UNEXPECTED_INTERRUPT
trap*
1x0C UNEXPECTED_INTERRUPT
1x0D UNEXPECTED_INTERRUPT
1x0E UNEXPECTED_INTERRUPT
trap
1x0F UNEXPECTED_INTERRUPT
fault*
1x10 UNEXPECTED_INTERRUPT
fault*
1x11 UNEXPECTED_INTERRUPT
page fault*
1x12 UNEXPECTED_INTERRUPT
78
Meaning
srs iar0 register
srs iar0 register
srs iar1 register
srs iar1 register
srs icr register
srs icr register
srs io_control reg-
ars io_fbb_en regis-
hvrs gmask register
hvrs gmask register
hvrs pamr resiter
hvrs papr register
hvrs papr register
hvrs dmode register
hvrs dmode register
hvrs pcicmd register
hvrs mltim register
hvrs brdg_feat reg-
hvrs pciror register
hvrs pciwor register
hvrs tltim register
Meaning
Interrupt occurred
HPMC
Powerfail interrupt
Recovery Counter
External Interrupt
LPMC
ITLB page fault*
Instruction mem pro-
Illegal instruction
Break instruction
Privileged instruc-
Privileged register
Overflow trap*
Conditional trap*
Assist exception
DTLB miss/page
Non-access ITLB
Non-access DTLB/
Data memory protec-
