Boot Console Interface Model C160L/160/180/200/240/360
Displaying and Setting the Monitor Type

Changing the Console to External Terminal

In the event that your console stops displaying to your
graphics device, use the following procedure to display to
console to an external terminal:
1 Turn system power off.
2 Disconnect the PC keyboard connector from the system
rear panel.
3 Connect a serial terminal to the Serial 1 connector (the
top serial connector) on the system rear panel.
4 Power on the system.
The system will now display the console to the terminal
connected to the Serial 1 port. Note that you can use a 9-pin
to 9-pin serial cable (HP F1044-80002) to connect an HP
OmniBook serial port to the workstation.
235
