Monitors - HP Visualize c100 Service Handbook

Product Information

Monitors

Monitors
The Models C100/C110/C200/C240/C360 do not have
a built-in graphics controller. A graphics board is
installed in on of the option slots. The Models C160L,
C160, and C180 have a graphics controller built-in on
the I/O board. The Model C180XP also comes with an
extended graphics adapter installed in an option slot.
The C Class workstations with built-in graphics sup-
ports using one of the following HP monitors:
• 17-inch, 1280x1024 color monitor (A4032)
• 20-inch, 1280x1024 color monitor (A4033)
• 17-inch, 1280x1024 color monitor (A4330)
• 20-inch, 1280x1024 color monitor (A4331)
The built-in monitor connector is a new Enhanced
Video connector. An EVC to DB adapter cable (HP
Part No. 8120-6861) is required to use monitors not
equipped with an EVC connector.
