HP Visualize c100 Service Handbook page 120

Troubleshooting
Selftest Failures
CDEE EISA_CARD_INIT_ERROR
capable system only)
CDEF NO_EISA_FOUND
capable system only)
CDFF INIT_SYSTEM_MAP_TABLE
map table
CHRONOLOGICAL EXAMPLE
C240+
Firmware Version 4.3
Manufacturing Mode
Single-ended FWSCSI/No-Graffiti I/O Board
EISA/550W Backplane Board
Fastboot OFF
1 pair of DIMMs
Not the first time it was booted with this memory config-
uration
INIT 10FC CHASSIS_FIND_CPUS
INIT C100 CHASSIS_MONARCH_SELECTED
TEST 3000 CHASSIS_ROM_XSUM_TEST
INIT 3000 CHASSIS_ROM_XSUM_TEST
TEST 3001 CHASSIS_PDH_CNTRL_TEST
INIT 3001 CHASSIS_PDH_CNTRL_TEST
INIT C4CC CHASSIS_INIT_CCP
INIT C4CF CHASSIS_CCP_FOUND
INIT C4CD CHASSIS_NO_CCP
INIT 3002 CHASSIS_SCR_SELFTEST
TEST 30BC CHASSIS_TEST_CPU_CLOCKS
INIT 30BC CHASSIS_TEST_CPU_CLOCKS
TEST C0FF CHASSIS_GSC_SLOT_TEST
INIT C30C CHASSIS_MONARCH_SLAVE_CHECK
INIT 10CA CHASSIS_RWAY_CPU_ARB
INIT C300 CHASSIS_MONARCH_TEST
TEST 1030 CHASSIS_STARTING_EST
TEST 1020 CHASSIS_CPU_BASIC
TEST 1021 CHASSIS_CPU_ALU
TEST 1022 CHASSIS_CPU_BR
TEST 1023 CHASSIS_CPU_ARITH_COND
TEST 1024 CHASSIS_CPU_BIT_OPS
TEST 1025 CHASSIS_CPU_CR
TEST 1026 CHASSIS_CPU_EXT_INT
TEST 1027 CHASSIS_CPU_ITIMER
TEST 1028 CHASSIS_CPU_MULTI_MEDIA
TEST 1029 CHASSIS_CPU_SHADOW
TEST 102A CHASSIS_CPU_DRS
TEST 102B CHASSIS_CPU_RDRS
TEST 102C CHASSIS_CPU_BYPASS
TEST 2010 CHASSIS_ICACHE_ALINE
TEST 201F CHASSIS_ICACHE_ALINE
starting from end of cache
TEST 2014 CHASSIS_ICACHE_ALINE
tiple of 0x40000 addr
TEST 2010 CHASSIS_ICACHE_ALINE
tiple of 0x40000 addr
TEST 2020 CHASSIS_ICACHE_RAM
TEST 2021 CHASSIS_ICACHE_RAM
first lines done
TEST 2022 CHASSIS_ICACHE_RAM
first lines done
TEST 2023 CHASSIS_ICACHE_RAM
rest of cache done
TEST 2023 CHASSIS_ICACHE_RAM
rest of cache done
TEST 2030 CHASSIS_CACHE_ITAG
TEST 2040 CHASSIS_CACHE_IERR
TEST 2060 CHASSIS_DCACHE_ALINE
TEST 2070 CHASSIS_DCACHE_RAM
92
(Expected in EISA-
(Expected in EISA-
Building the system
Loop
Next mul-
Next mul-
Test
Load
Test
Test
