Configuration
Graphics Configurations
Graphics Configuration Restrictions
This subsection describes restrictions on the installa-
tion and support of graphics adapters.
The system supports only four
Graphics Displays
graphics displays at a time. A "display" is a video out-
put port or connector. For example, the Dual Visualize
Enhanced Graphics Card (A4451A) is a dual display
card. It has two external video connectors so it
accounts for two of the maximum of four displays. If
you install two of these cards they account for four
displays, which is the maximum supported by the sys-
tem.
The built-in graphics adapter accounts for one graph-
ics display
(graphics(0)). If four displays are installed in the
option slots, the built-in graphics adapter is automati-
cally disabled.
You may not install a dual
Dual Graphics Adapters
display graphics adapter in option slot 1 and option
slot 3 at the same time. Installing a dual display graph-
ics adapter in option slot 1 and option slot 3 at the
same time results in the graphics adapter in slot 1
being disabled.
You may not install a dual display graphics adapter in
option slot 2 and option slot 4 at the same time. Install-
ing a dual display graphics adapter in option slot 2 and
option slot 4 at the same time results in the graphics
adapter in slot 2 being disabled.
When a Visualize48Z
Multi-board Graphics Adapters
(A4244A) two board graphics adapter is installed,
Only one other graphics adapter may be installed in
the option slots. If the highest numbered slot used by
the Visualize 48Z board set is an even numbered slot,
then you may only install a graphics card in the
