Installing Memory Modules - HP Visualize c100 Service Handbook

Field Replaceable Units
FRU Removal and Replacement
2 To install a memory module, close the ejector tabs on
NOTE: The C160L memory orientation is rotated 180 degrees from
the C160/180/200/240/360.
Figure 41

Installing Memory Modules

3 Press firmly and evenly on the memory module to ensure
4 To verify that this installation was successful, display the
128
each side of the memory connector. This lowers the force
needed to seat the memory board.
Line the memory module up with the guides, as shown
in Figure 41. Make sure that the notched end of the
memory module is to the left, as shown in Figure 41.
that it is fully seated.
current memory information using the Boot Console In-
terface.
For more information on the Boot Console Interface, see
Chapter 9 of this manual.
