Allowable Memory Configurations
The Model C100/110/160L workstations have 8 mem-
ory slots, labeled 0A, 0B through 3A, 3B. The mem-
ory configuration is 32 MB to 512 MB installed in
pairs of 16 MB, 32 MB, or 64 MB memory modules.
The Model C160/180XP/200/240/360 workstations
have 12 memory slots, labeled 0A, 0B through 5A,
5B. The memory configuration is 32 MB to 1.5 GB
installed in pairs of 16 MB, 32 MB, 64 MB or 128 MB
memory modules.
Memory modules must be installed in pairs of equal
capacity.
Always install the largest capacity memory modules in
the lowest numbered memory slots and don't skip any
numbers.
For example, if you have a pair of 16 MB memory
modules and a pair of 64 MB memory modules, first
install the pair of 64 MB memory modules in slots 0A
and 0B, then install the 16 MB modules in slots 1A
and 1B.
Figure 17 shows the positions of the memory connec-
tors on the Models C100/110 CPU board.
Figure 18 shows the positions of the memory connec-
tors on the Model C160L CPU board.
Figure 19 shows the positions of the memory connec-
tors on the Models C160/180XP/200/240/360 CPU
board.
