Installing the Server
These topics describe how to install the server into a rack using the rail assembly in the
rackmount kit. Perform these procedures if you purchased the rail assembly.
Note -
Step
Description
1.
Install optional components.
2.
Ensure that your rack is compatible with the server
requirements.
3.
Review the cautions for working with racks.
4.
Use antitilt mechanisms to ensure that the rack does not
tip when the server is installed.
5.
Prepare the slide rails, mounting brackets, and slide rail
assemblies for server installation.
6.
Install the server in the rack.
7.
(Optional) Install the CMA.
Related Information
"Preparing for Installation" on page 29
■
"Connecting Cables" on page 59
■
Optional Components
Optional components, such as additional memory or PCIe cards that were ordered as part of
the server, are installed in the server at the factory before the server is shipped. Any options
In this guide, the term "rack" means either an open rack or a closed cabinet.
Links
"Optional Components" on page 33
"Rack Compatibility" on page 34
"Rack Cautions" on page 35
"Stabilize the Rack" on page 36
"Install the Rackmount Hardware" on page 37
"Attach Slide Rail Assemblies to the Rack" on page 39
"Install the Server Into the Slide Rail Assemblies" on page 43
"Attach the CMA to the Server" on page 49
Installing the Server
33
