Connect the SER MGT Cable
The SP serial management port is labeled SER MGT. Use the SER MGT port only for server
management. This port is the default connection between the SP and a terminal or a computer.
Do not attach a modem to this port.
Caution -
Connect a Category 5 (or better) RJ-45 cable from the SER MGT port to a
1.
terminal device.
Use an RJ-45 cable that is set up for a null modem configuration, in which the transmit and
receive signals cross over. You can use a crossover adapter with a standard RJ-45 cable
Connect the SER MGT Cable
Connecting Cables
67
