No. Description
3 PCIe slot 1
4 PCIe slot 2
5 PCIe slot 3
6 PCIe slot 4
7 PCIe slot 5
8 PCIe slot 6
9 Network 100/1000/10000 ports: NET 0 to NET 3
10 NET MGT RJ-45 network port
11 SER MGT RJ-45 network port
Note Some configurations provide slots for two rear 2.5-inch drives. RHDD 0 is above
Power Supply 0. RHDD 1 is above Power Supply 1.
Related Information
"Front Panel Components With Eight-Drive Backplane (Installation)" on page 14
■
"Front Panel Components With Twelve-3.5-Inch-Drive Backplane
■
(Installation)" on page 15
"Front Panel Components With Twenty-Four-Drive Backplane
■
(Installation)" on page 17
"Front Panel Components With Twelve NVMe Drive Backplane
■
(Installation)" on page 19
"Cabling Requirements" on page 59
■
"Attach the CMA to the Server" on page 49
■
"Secure Cables to the CMA" on page 72
■
Rear Panel Components (Installation)
