No.
8
9
10
Related Information
"Prepare the CMA for Installation" on page 47
■
"Attach the CMA to the Server" on page 49
■
"Verify Operation of Slide Rails and CMA" on page 55
■

Prepare the CMA for Installation

Follow this procedure to prepare the optional CMA for installation at the rear of the server.
Install the server in the rack before attaching the CMA.
1.
See "Install the Server Into the Slide Rail Assemblies" on page
2. Unpack the CMA.
See "CMA Components"
3. Ensure that the correct cable covers for your server are installed on the CMA.
This server uses the round cable covers.
The CMA ships with three, flat cable covers installed. Before installing the CMA, you
Note -
must replace the flat cable covers with the round cable covers. If the round cable covers are
already on the CMA, skip the next step.
4. (If needed) Remove the flat cable covers and install the round cable covers.
To remove the flat cable covers and install the round cable covers, perform these steps:
a. Lift up on the cable cover handle (the handle is green) and open it 180
degrees to the horizontal position (panels 1 and 2).
Description
Rear slide bar
Flat cable covers (not used with this server)
Round cable covers
Prepare the CMA for Installation
43.
Installing the Server 47
