Front Panel Components With Twenty-Four-Drive
Backplane (Installation)
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Front Panel Components With Twenty-Four-Drive Backplane (Installation)
Description
Locator button / Locator LED (white)
Service Required LED (amber)
Power LED (green)
Power button
SP Power OK button (green)
Server serial number
Drive 0
Drive 1
Drive 2
Drive 3 (or NVMe drive 0)
Drive 4 (or NVMe drive 1)
Drive 5
Drive 6
Drive 7
Drive 8
Drive 9
Understanding the Server
