Operating menu

Analog input source

Navigation
Prerequisite
Description
Selection
Factory setting
Additional information
198
 Setup → Advanced setup → Input/output → Analog I/O → Analog source
Operating mode (→  196) = 4..20mA output or HART slave +4..20mA output
Defines the value which will be transmitted via the Analog I/O module.
• Tank level
• Liquid temperature
• Vapor temperature
• Water level
• P1 (bottom)
• P2 (middle)
• P3 (top)
• Observed density value
• Volume
• Flow velocity
• Volume flow
• Vapor density
• Middle density
• Upper density
• Correction
• Tank level %
• GP 1 ... 4 value
• Measured level
• P3 position
• Tank reference height
• Local gravity
• P1 position
• Manual density
• Tank ullage
• Average profile density
• Lower density
• Upper interface level
• Lower interface level
• Bottom level
• Displacer position
• HART device 1 ... 15 PV
• HART device 1 ... 15 SV
• HART device 1 ... 15 TV
• HART device 1 ... 15 QV
• HART device 1 ... 15 PV mA
• HART device 1 ... 15 PV %
• Element temperature 1 ... 24
• AIO B1-3 value
• AIO C1-3 value
• AIP B4-8 value
• AIP C4-8 value
• None
Tank level
Read access
Write access
Operator
Maintenance
