Proservo NMS83
Additional information
Tank reference height
Navigation
Description
User entry
Factory setting
Additional information
Tank level
Navigation
Description
Additional information
Set level
Navigation
Description
User entry
Factory setting
Additional information
Endress+Hauser
Read access
Write access
The reference point is the reference line of the calibration window.
 Setup → Advanced setup → Application → Tank config → Level → Tank ref height
Defines the distance from the dipping reference point to the zero position (tank bottom or
datum plate).
0 to 100 000 mm
Dependent on the device version
Read access
Write access
 Setup → Advanced setup → Application → Tank config → Level → Tank level
Shows the distance from the zero position (tank bottom or datum plate) to the product
surface.
Read access
Write access
 Setup → Advanced setup → Application → Tank config → Level → Set level
If the level measured by the device does not match the actual level obtained by a manual
dip, enter the correct level into this parameter.
0 to 100 000 mm
0 mm
Read access
Write access
Operator
Maintenance
Operator
Maintenance
Operator
-
Operator
Maintenance
Operating menu


237
