Real-time Kinematic Measuring

Setting up an RTK Base Station

www.javad.com
6. Move the Rover receiver along the selected trajectory.
7. Once the Rover receiver reaches the end point of the trajectory,
pause for several minutes.
8. When finished, press the FN key to stop logging data and turn off
the Rover.
Real-time kinematic (RTK) is a differential GPS process where
information, such as differential corrections, is transmitted in real-time from
a Base station to one or more Rover stations.
To configure an RTK Base station using PCView, take the following
steps:
1. Set up the Base station receiver's antenna as described in "Maxor
Receiver Setup" on page 3-2.
2. Connect an external modem to port D for the Maxor receiver.
3. Press the power key on the receiver.
4. Check the STAT light for tracked satellites.
5. Connect your receiver and computer. See "Connecting the Maxor
and a Computer" on page 2-9 for this procedure.
6. Click Configuration->Receiver.
S E T U P A N D M E A S U R I N G
Measuring with the Maxor
Maxor Operator's Manual 3-13
