Notice: Only use this procedure if the receiver does not respond
to commands or does not charge the internal batteries (is
in Zero Power Mode).

FN Key and Record LED

www.javad.com
Table 4-1 summarizes FN key functions and REC LED statuses. See "FN
Key Mode parameter" on page 2-23 for information on setting FN key
modes.
• Pressing the FN key for less than one second switches the receiver
between different information modes (normal and extended
information), or between static and dynamic post-processing modes,
depending on the receiver's configuration.
During the first second of pressing the FN key, the REC LED is orange.
• Pressing the FN key for more than one and less than five seconds will
start/stop data recording.
During data recording the REC LED is green or orange.
If the REC LED is red, the receiver has run out of memory, has a
hardware problem, or contains an improper OAF (see "Option
Authorization File (OAF)" on page 1-14 for more information on
OAFs).
• The REC LED blinks green or orange each time data is written to the
internal receiver's memory.
You set the data recording time interval using PCView. See "Recording
Interval parameter" on page 2-21 for information on setting this
function.
Each time you turn off or on data recording, either a new file opens or
data appends to a particular file. See "Always Append to the File
parameter" on page 2-22 and "Files Creation Mode parameter" on
page 2-22 for information on setting this function.
• Pressing the FN key for more than five and less than eight seconds will
turn the baud rate of serial port A to 9600. After about five seconds of
pressing the FN key, the REC LED becomes red. Release the FN key
while the REC LED is red (during the next three seconds).
Pressing the FN key for more than eight seconds has no impact.
O P E R A T I O N
Using MinPad
Maxor Operator's Manual 4-3
