GPS External Antenna RF Connector

EVENT and 1PPS Connectors (Optional)

www.javad.com
The external antenna connector type (Table B-11) is a TNC RF
connector with an Applied Engineering Product part number 6001-
7051-003.
Type Signal Name
TNC ANT_IN
The EVENT and 1PPS connectors are coaxial female receptacles of
BNC series, Kings Electronics part number KC-79-108. These
connectors are optional.
Table B-11.
Dir
RF input from LNA, 100 mA
I
at 5.0 volts DC output
Maxor Operator's Manual B-15
