Using MinPad
When data recording is OFF, and the FN key is...
Not pressed
Pressed for < 1 second
Pressed for 1–5
seconds
Pressed for 5–8
seconds
Pressed for > 8
seconds
4-4 Maxor Operator's Manual
• After loading new firmware or clearing the receiver's NVRAM, the
receiver checks its internal file system.
During this operation, the REC LED flashes orange, and the file system
is not accessible for CDU (control display unit) applications or for data
recording. This operation may require from fractions of a second to
several minutes, depending on the circumstances and the amount of
internal memory.
Table 4-1. FN Key Functions and REC LED Status
FN Key REC LED
No light
Orange blink
Red
If FN key mode is «LED blink mode switch»
Orange
If FN key mode is «Occupation mode switch»
Orange
If FN key mode is «LED blink mode switch»
Green
If FN key mode is «Occupation mode switch»
Green
Red
No light
Status
No data recording.
Internal file system test in progress.
No free memory; hardware problem with
data recording.
Release to charge information mode.
No function.
Release to start data recording (post-
processing occupation mode undefined).
Release to start recording (Kinematic or
Static post-processing occupation mode).
Release to turn serial port A baud rate to
9600 bps.
No function.
