C O N F I G U R A T I O N
2
Bluetooth® Module Configuration
Bluetooth® Module Configuration
Use BTCONF, the Bluetooth® module's configuration program, and your
computer to:
• access the Bluetooth® wireless technology module
• configure the Bluetooth® module
• check or change the module's configuration
To access the Bluetooth® wireless technology module, first download and
install BTCONF, then connect your computer and the receiver and run the
configuration program.
Create or locate the following folder:
1.
Download btconf.zip from the JNS website (http://www.javad.com) and
2.
unzip it into the BTCONF folder. This file contains Btconf.exe, the
executable file for the Bluetooth® module configuration program.
To uninstall, or remove, BTCONF, delete any applicable BTCONF directories
or folders, and any BTCONF shortcuts.
Once you have BTCONF available, follow these steps to configure the
Bluetooth® module.
Using the RS232 cable, connect the serial port of your computer to the
1.
receiver's serial port A.
Press the power buttons on the receiver and computer to turn them on.
2.
Run the Bluetooth® module configuration program (Btconf.exe) (Figure 2-
3.
30).
2-40 Maxor Operator's Manual
C:\Program Files\JNS\BTCONF
Figure 2-30. Bluetooth® Module Configuration Main Screen
