S E T U P A N D M E A S U R I N G
3
Maxor Receiver Setup
3. Record the antenna height, point name, and start time in the field notes.
4. Attach the flexible RF cable from the external antenna to the antenna
5. Turn on the Maxor and continue with step 3 on page 3-4.
The Maxor antenna default is set to Auto, allowing the receiver to detect
automatically the available antenna (whether internal or external). If you
have changed this setting, or the receiver does not detect the external
antenna, use the procedure below to set the External Antenna detection
option.
1. Connect your receiver and computer. See "Connecting the Maxor and a
2. Start PCView.
3. Click on Configuration->Receiver (Figure 3-3).
4. On the General tab, select the External Antenna option (Figure 3-4).
3-6 Maxor Operator's Manual
connector on the bottom panel of the Maxor.
Computer" on page 2-9 for this procedure.
Figure 3-3. Configuration->Receiver
Figure 3-4. Select External Antenna Option
