C O N F I G U R A T I O N
2
Connecting the Maxor and a Computer
3. Once the Master device detects the receiver, use the procedure
4. Once connected, continue with Step 1 in "Establishing a PCView
If you cannot establish a connection, check that the receiver's slot three is
enabled.
1. Connect your receiver and a computer using an RS232 cable (see
2. Start PCView.
3. Click Configuration->Receiver->General.
4. In the Turn on/off Slots area, ensure the Slot 3 (B) check box is

Establishing an RS232 Cable Connection

1. Using the RS232 cable, connect the serial port of your computer
2. Press the power buttons on the receiver and computer to turn them on.
3. Continue with Step 1 in "Establishing a PCView Connection" on

Establishing a USB Cable Connection

Make sure the computer has JNS's USB driver installed (available from
Support area Free Software section of http://www.javad.com) before
continuing.
1. Using the USB cable, connect the USB port on the receiver to a USB
2. Press the power buttons on the receiver and computer to turn them on.
3. Continue with Step 1 in "Establishing a PCView Connection" on
2-10 Maxor Operator's Manual
described in the external device's documentation to connect it with the
receiver.
Connection" on page 2-11.
"Establishing an RS232 Cable Connection" ).
enabled.
(usually COM1) to the receiver's serial port A.
page 2-11.
port on the computer.
page 2-11.
