• Battery B – displays the voltage of battery B.
• Charger – displays the charger's output voltage during battery
charging.
• On Ports – displays the voltage output on pin one of all serial ports
connectors.
9. Select and check each of the Turn on/off Slots check boxes to enable
the corresponding internal slots (Figure 2-7).
10. Select and check the Enable Low Power Mode check box to put the
receiver's processor into low power consumption mode (Figure 2-8).
Figure 2-8. Activate Low Power Mode
11. Click Apply.
Figure 2-7. Enable Slots
C O N F I G U R A T I O N
Powering the Maxor
Maxor Operator's Manual 2-7
