Powering the Maxor

Powering the Maxor

You can power the receiver using:

• Internal batteries

• External DC power source (user-supplied)

• A battery charger
Internal Batteries
With a full charge, and depending on the type and mode of the on-board
radio modem, the internal batteries should power both the GPS receiver and
the radio modem according to the times listed in Table 2-1.
External DC Power Source (user-supplied)
In addition to the internal batteries, you can power your receiver with an
external power source. The use of external power source allows you to
continue using the receiver in case the internal batteries are discharged. The
appropriate external power source must provide + 6 to +28 V DC and must
2-2 Maxor Operator's Manual
Table 2-1. Average Operating Times
Modem Type/Mode
Any/Off
UHF/On and in Receiving
mode only
UHF/On and in 1 Watts
Transmitting mode
UHF/On and in 2 Watts
Transmitting mode
a
GSM/Standby mode
b
GSM/Data Transfer mode
a. In this mode, the GSM modem is ready to transmit or receive data,
without being used for an actual data transfer.
b. In this mode, the GSM modem transmits or receives data.
Maxor GG/
Maxor GGD
GD
17 hours 14 hours
15 hours 12 hours
9 hours 8 hours
14 hours 11.5 hours
11 hours 10 hours
Maxor GGDT
18 hours
16 hours
10 hours
7 hours
13 - 15 hours
13 - 15 hours
