Javad Maxor Operator's Manual page 76

C O N F I G U R A T I O N
2
Bluetooth® Module Configuration
• Firmware version – the current firmware version of the Bluetooth®
module.
The COM port and baud rate are displayed in the lower left corner.
Click the Parameters tab (Figure 2-33). The Parameters tab sets
6.
identifying and security information for your Bluetooth® module. The
security section allows you to set data security and unauthorized access
parameters for the Bluetooth® module.
Enter up to 14 characters to set a unique name for the Bluetooth® module
7.
(Figure 2-33), and click Apply
To set security parameters (Figure 2-33 on page 2-42), enter and enable the
8.
following, then click Apply:
• Bluetooth® PIN – enter up to 16 characters to specify a personal
identification number for the Bluetooth® module.
2-42 Maxor Operator's Manual
Figure 2-32. BTCONF Identification Tab
Figure 2-33. BTCONF Parameters Tab
www.javad.com
