C O N F I G U R A T I O N
2
MinPad Configuration
You use PCView to configure MinPad settings. Refer to the PCView Software
Manual for all possible MinPad configurations.
Connect your receiver and computer. See "Connecting the Maxor and a
1.
Computer" for this procedure.
Start PCView.
2.
On the Connection Parameters dialog box, enable RTS/CTS handshaking
3.
(Figure 2-19) and then click Connect.
Click Configuration->Receiver (Figure 2-20).
4.
Click the MinPad tab, set the following parameters and click Apply
5.
(Figure 2-21). See the following pages for descriptions of these parameters.
• Recording interval on page 2-21
• Elevation mask for log file on page 2-21
• File name prefix on page 2-21
• Always append to the file on page 2-22
• Files Creation mode on page 2-22
• Automatic File Rotation Mode (AFRM) on page 2-22
2-20 Maxor Operator's Manual
Figure 2-19. Connection Parameters – RTS/CTS Handshaking
Figure 2-20. Configuration->Receiver
