Operation
5.3.4
LED D2 = green
At the menu Settings > Adjustment, you can use either a two-point adjustment or a Zero-point adjust-
ment. In this menu, the controller can also be reset to the factory settings.
Two-point adjustment Here you can set any 2 points within the measuring range and the corresponding
Factory settings
Zero-point adjustment This is a special case of a two-point adjustment and provides the best performance
Fig. 54 Graphic Two-point adjustment
induSENSOR DTD / MSC7xxx

Adjustment

signal values.
The controller can be reset to the parameters stored by
for the measuring system. The first of the two points is the electrical zero point at
which a differential sensor shows the highest stability on principle.
V
2
V
1
X X
1 2
V
0
V
2
X X
2 0
Fig. 55 Graphic Zero-point adjustment
default, see A 2.
