Operation
5.4.6

Example D: Adjustment via Two-point Adjustment, Channel 1

D1 D2 D3
G
MENU
R
G G
G G
ENTER
G G G
G G R
ENTER
R
G
G
ENTER
G G
R
ENTER
G R G
induSENSOR DTD / MSC7xxx
Set the sensor parameters according to example A and connect the output signal according to
D4
example B.
Press the MENU button for 3 seconds, if you are not yet in the menu.
Output situation: The sensor parameters are already set; depending on the approach, LED D4 is
green or switched off.
Go to the menu
Confirm by pressing the ENTER button.
Select two-point adjustment.
Confirm by pressing the ENTER button.
Now move the measuring object to the desired position start of measuring range (X
Use the arrow buttons to set 2.00 V (V
Confirm by pressing the ENTER button.
Now move the measuring object 6.000 mm towards
the end of the measuring range (X
Use the arrow buttons to set 10.000 V (V
Confirm by pressing the ENTER button.
Adjustment, see
5.3.4.
).
1
).
2
).
2
(10 V)
V
2
(2 V)
V
1
X X
6 mm
1 2
Fig. 61 Example Two-point adjustment
).
1
