Installation and Assembly
4.2.3
Fasten the controller of series MSC7802 by means of two M4
The position of the mounting holes is shown in the
The tightening torque for the cover screws is 0.9 Nm. The maximum tightening torque for the SW15 (M12)
cable gland is 1.5 Nm and for the SW19 (M16) cable gland is 3 Nm.
Please note that less torque should be applied for cable glands with various cable sheath materials.
> Damage to the cable sheath
induSENSOR DTD / MSC7xxx
MSC7802 Model
screws, see Fig.
drawing, see Fig.
6.
6.
Page 20
