Appendix | Software
A 3.7
Multi-Sensor DAQ Mode
The sensorTOOL also offers the possibility to output the data from several channels of the induSENSOR DTD / MSC7xxx series.
i
Please note that the RS485 interface is a serial bus.
Even if the measured values are output simultaneously in sensorTOOL, they are recorded with a time delay.
To output the data of several bus participants into one graph, please proceed as follows:
Search for the controller via the sensorTOOL
i
Please note that the checkbox Quick scan RS485 must be
Fig. 87 First interactive site after calling the sensorTOOL
induSENSOR DTD / MSC7xxx
program, see A
3.1.
deactivated, see Fig.
87, to find multiple channels.
Page 93
