Fig. 74 View 3 Two-point adjustment
i
1) Sensor designation, e.g., DTA-3G8 Custom
The chart is divided into 3 areas:
Green Taught-in range, limited by X
White Usable range outside the taught-in range
Red
induSENSOR DTD / MSC7xxx
Optionally, you can enter the associated millimeter values which can be found under Measurement
and the additional designation Custom
Unavailable range
, see Fig.
78.
1
, X
and the associated output signals.
1
2
