Operation
5.4.4 Example B: Signal Output Adjustment: 2 ... 10 V, Channel 1
D1 D2 D3
G
MENU
R
G G
G G
O
ENTER
G O G
G O O
ENTER
G O O
ENTER
G R G
induSENSOR DTD / MSC7xxx
D4
Press the MENU button for 3 seconds, if you are not yet in the menu.
Output situation: The sensor parameters are already set; depending on the approach, LED D4 is
green or switched off.
Signal, see
Menu point:
tion; depending on the output load, the LED D4 is red (4 ... 20 mA) or orange
(2 ... 10 V). If the automatic settings suits you, you can cancel example B here.
Confirm by pressing the ENTER button.
Voltage output
Confirm by pressing the ENTER button.
O 2 ... 10 V; with
Confirm by pressing the ENTER button.
Output situation: The sensor parameters are already set; depending on the approach, LED D4 is
green or switched off.
5.3.2; in delivery state, the electronics works with automatic load recogni-
the selection can be changed here.
