Installation and Assembly
4.2
4.2.1
Fig. 2 Dimensional drawing of DTD controller, dimensions in mm (inches)
Fig. 3 Dimensional drawing of mounting clamp, dimensions in mm (inches)
induSENSOR DTD / MSC7xxx

Controller

DTD Model

When mounting the controller, use the mounting clamp included in
M3 screw.
Ferrite
Depth: 7.94 mm
Ø3.2
(.13 dia.)
22.6
Through-hole
(.89)
56 (2.2)
10
28 (1.1)
(.39)
9
8(35)
delivery, see 3.1, as well as a suitable
10
(.39)
