  • Page 1 Operating Instructions MSC7401...
  • Page 2 Miniature sensor controller for inductive sensors MICRO-EPSILON MESSTECHNIK GmbH & Co. KG Koenigbacher Strasse 15 94496 Ortenburg / Germany Tel. +49 (0) 8542 / 168-0 Fax +49 (0) 8542 / 168-90 e-mail info@micro-epsilon.de www.micro-epsilon.com...

  • Page 3: Table Of Contents

    Operation ..........................19 Initial Operation .............................. 20 Control and Display Elements ........................21 Setting ................................22 5.3.1 Automatic Sensor Recognition..................... 23 5.3.2 Signal ............................23 5.3.3 Sensor Parameter ......................... 24 5.3.4 Adjustment ............................ 25 MSC7401 Miniature sensor controller for inductive sensors...
  • Page 4 Settings ................................. 47 A 3.3.1 General ............................47 A 3.3.2 Output ............................49 A 3.3.3 Adjustment ............................ 50 A 3.3.3.1 Two Point ........................50 A 3.3.3.2 Zero Point ........................53 A 3.4 Info ................................. 56 MSC7401 Miniature sensor controller for inductive sensors...

  • Page 5: Safety

    > Damage to or destruction of the controller and/or the sensor The supply voltage must not exceed the specified limits > Damage to or destruction of the controller and/or the sensor MSC7401 Miniature sensor controller for inductive sensors Page 5...

  • Page 6: Notes On Ce Marking

    The measuring system is designed for use in industrial environments and meets the requirements. Intended Use The MSC7401 measuring system is designed for use in industrial areas. It is used to operate inductive displacement sensors based on the LVDT principle (Linear Variable Differential Transformer) and for operation with LDR displacement sensors.

  • Page 7: Proper Environment

    5 - 95 % (no condensation) - Ambient pressure: Atmospheric pressure - Protection class: IP 67 - Storage temperature: -40 to +85 °C (-40 to 185 °F) - Vibration/Shock: EN 60068-2 MSC7401 Miniature sensor controller for inductive sensors Page 7...

  • Page 8: Functional Principle, Technical Data

    Functional Principle, Technical Data Functional Principle The MSC7401 is a single-channel miniature sensor controller for the operation of LVDT inductive displace- ment sensors (full bridge) and for half-bridge sensors. An electronic oscillator excites the primary coil with an alternating current of a constant frequency. The fre- quency and amplitude can be set for best operation mode of the respective sensors, see Chap.

  • Page 9: Design

    MICRO-EPSILON recommends the inductive displacement sensors and gauging sensors of the induSENSOR DTA and LDR series because they are optimally adjusted with the controller.
  • Page 10 4) The output signal is limited to 21 mA for controller with current output. 5) Noise: AC RMS measurement via RC low-pass filter of the 1st order with fc = 5 kHz 6) Only adjustable via software. 7) When using suitable cables or plugs. MSC7401 Miniature sensor controller for inductive sensors Page 10...

  • Page 11: Delivery

    If there is damage or parts are missing, immediately contact the manufacturer or supplier. Optional accessories are available in the appendix, see Chap. Storage Storage temperature: -40 up to +85 °C (-40 to +185 °F) Humidity: 5 - 95 % (no condensation) MSC7401 Miniature sensor controller for inductive sensors Page 11...

  • Page 12: Installation And Assembly

    Check all the connectors for tightness of fit before the equipment is started. Pay attention to careful handling during installation and operation. Controller Fasten the controller of series MSC7401 by means of two screws M4. The position of the mounting holes is shown in the drawing, see Fig.
  • Page 13 Clamping range 4.5 mm ... 10 mm Alternative (option 010): Alternative (option 010): M9 5-pole socket M12x1 plug; 5-pole Series 712 (Binder) Fig. 2 Dimensions of the controller, dimensions in mm (inches), not to scale MSC7401 Miniature sensor controller for inductive sensors Page 13...

  • Page 14: Power Supply, Sensor And Signal Output

    Connection screw terminals; AWG 16 up to AWG 24; up to AWG 28 with ferrule ƒ alternatively: Female connector M9; 5-pole, series 712, Co. Binder Fig. 3 View with cable gland, MSC 7401 Fig. 4 View with plug-in connectors, MSC 7401 (option 010) MSC7401 Miniature sensor controller for inductive sensors Page 14...
  • Page 15 Pin 1 Shield Shield Fig. 6 Table for the pin assignment for the sensor at the terminal block X2, full bridge 1) The colors and pins listed apply to MICRO-EPSILON displacement sensors. MSC7401 Miniature sensor controller for inductive sensors Page 15...
  • Page 16 You will find the pin assignment for the terminal block in the table, see Fig. 9, see Fig. 10, see Fig. 1) The colors and pins listed apply to MICRO-EPSILON displacement sensors. MSC7401 Miniature sensor controller for inductive sensors Page 16...

  • Page 17: Power Supply And Signal

    Output signal Center tap RS485 B Power supply Secondary coil + Power supply / signal ground Secondary coil - Housing/Shield Primary coil + Primary coil - Fig. 10 Pin assignment terminal blocks MSC7401 Miniature sensor controller for inductive sensors Page 17...

  • Page 18: Sensor

    Description Secondary + Secondary - Primary + Primary - View on solder pin side Secondary medium tab Fig. 12 Pin assignment sensor, female connector M9, 5 -pole. series 712, Fa. Binder MSC7401 Miniature sensor controller for inductive sensors Page 18...

  • Page 19: Operation

    Let the controller and the sensor connected warm up for approx. 2 minutes when the power supply is switched on before you perform any measurement or setting. Observe the operating instructions of the sensors used. If a sensor is replaced, the channel must be re-parameterized and readjusted. MSC7401 Miniature sensor controller for inductive sensors Page 19...

  • Page 20: Initial Operation

    Chap. Then switch on the power supply. Set the controller to its basic setting, see Chap. 5.3. DOWN ENTER MENU Fig. 13 Controller MSC7401 Miniature sensor controller for inductive sensors Page 20...

  • Page 21: Control And Display Elements

    D3 LED Display E2 menu level sponding settings. The LED Value indicates the current D4 LED Display Value value of the selected parameter. Fig. 14 Control and Display Elements MSC7401 Miniature sensor controller for inductive sensors Page 21...

  • Page 22: Setting

    Operation Setting The menu of the MSC7401 is designed for fast, mainly automated commissioning as well as for individual application-specific settings. It is divided into four function blocks, see Fig. 15. The 4 LEDs show the cur- rent position in the menu and the corresponding setting value at any time, see Chap. 5.4. Alternatively, the software SensorTool, see Chap.

  • Page 23: Automatic Sensor Recognition

    Automatic recognition is available. For a load at the output of: > 1 kOhm, voltage output 2 ... 10 V is set, < 1 kOhm, current output 4 ... 20 mA is set. MSC7401 Miniature sensor controller for inductive sensors Page 23...

  • Page 24: Sensor Parameter

    LDR-14 with 8 mm drawbar 14 mm with 10 mm drawbar LVP-25 with 8 mm drawbar 25 mm with 10 mm drawbar 16 kHz Fig. 16 Sensor models and sensor parameters MSC7401 Miniature sensor controller for inductive sensors Page 24...

  • Page 25: Adjustment

    The first of the two points is the electrical zero point at which a differential sensor shows the highest stability on principle. Fig. 17 Graphic 2-point adjustment Fig. 18 Graphic Zero point search MSC7401 Miniature sensor controller for inductive sensors Page 25...

  • Page 26: Menu Structure

    LED green LED green flashing LED red LED red flashing LED off Start of measuring range Midrange End of measuring range Fig. 19 Legend menu structure 1) To pages 26 to 33 MSC7401 Miniature sensor controller for inductive sensors Page 26...
  • Page 27 2 ... 10 V Voltage 0 ... 5 V Signal E1 level ENTER ENTER ENTER 0.5 ... 4.5 V 4 ... 20 mA Current 0 ... 20 mA 0 ... 10 mA MSC7401 Miniature sensor controller for inductive sensors Page 27...
  • Page 28 13 kHz Frequency 5 kHz 16 kHz 10 kHz 21 kHz ENTER 550 mV 350 mV Amplitude E1 level ENTER 150 mV 75 mV Fig. 20 Menu structure Controller MSC 7401 MSC7401 Miniature sensor controller for inductive sensors Page 28...

  • Page 29: 2-Point Adjustment

    Fig. 21 Menu structure controller MSC 7401, Adjustment mode: 2-point adjustment 1) Position X must be > 10 % of the measuring range from X MSC7401 Miniature sensor controller for inductive sensors Page 29...

  • Page 30: Zero Point Search

    > 10 % of the trical center of the measuring sensor. range from X Fig. 22 Menu structure controller MSC 7401, adjustment mode: Zero point search MSC7401 Miniature sensor controller for inductive sensors Page 30...

  • Page 31: Example A: Sensor Parameter Adjustment: Dta-5G8

    Confirm by pressing the ENTER button. ENTER Excitation voltage: 550 mV; with the selection can be changed here. Confirm by pressing the ENTER button. ENTER MSC7401 Miniature sensor controller for inductive sensors Page 31...

  • Page 32: Example B: Signal Output Adjustment: 2

    Confirm by pressing the ENTER button. ENTER Output situation: The sensor parameters are already set; depending on the approach, LED D4 is green or switched off. MSC7401 Miniature sensor controller for inductive sensors Page 32...

  • Page 33: Example C: Adjustment Via Zero Point Search

    ) and use the arrow buttons to set 2.00 V (U For better orientation, LED D4 changes the color depending on the plunger position. Near the zero point, LED D4 flashes orange. Confirm by pressing the ENTER button. ENTER MSC7401 Miniature sensor controller for inductive sensors Page 33...

  • Page 34: Example D: Adjustment Via 2-Point Adjustment

    (X Use the arrow buttons to set 10.000 V (U Confirm by pressing the ENTER button. ENTER (2 V) 6 mm Fig. 24 Example 2-point Adjustment MSC7401 Miniature sensor controller for inductive sensors Page 34...

  • Page 35: Service, Repair

    Within this period, defective parts, except for wearing parts, will be repaired or replaced free of charge, if the device is returned to MICRO-EPSILON with shipping costs prepaid. Any damage that is caused by improper handling, the use of force or by repairs or modifications by third parties is not covered by the liability for mate- rial defects.

  • Page 36: Appendix A 1 Accessories

    A-coding, length: 5 m, 5-core, open ends, AD: 5.6 mm, IP 67 IF 7001 Single channel USB/RS485 converter for MSC7xxx You will find further information to IF 7001 under: https://www.micro-epsilon.com/download/manuals/ass-- IF-7001--en.pdf MSC7401 Miniature sensor controller for inductive sensors Page 36...

  • Page 37: A 2 Factory Settings

    - Automatic recognition of customer signals - Automatic sensor recognition Upon successful recognition: - Start of measuring range (Plunger pulled-out): ~2 V or 4 mA - Midrange (Electric zero): ~6 V or 12 mV Language: German MSC7401 Miniature sensor controller for inductive sensors Page 37...

  • Page 38: A 3 Software

    In the drop down menu, set the sensor groups induSENSOR, Sensortype induSENSOR MSC7xxx and activate the other settings according to the figure below, see Fig. Fig. 25 Main view Then click the Search button. MSC7401 Miniature sensor controller for inductive sensors Page 38...
  • Page 39 Choose the desired language by clicking on the respective flag icon. Fig. 26 Language German Fig. 27 Language English Click the Configure Serial Interface button to set the basic settings for the serial interface. Fig. 28 Window Search Results MSC7401 Miniature sensor controller for inductive sensors Page 39...
  • Page 40 Fig. 29 Window Change Serial Configuration - SensorTool Tip: Set the baud rate to 256,000 Baud. Start the data acquisition/configuration by clicking Start Data Acquisition or the controller picture, see Fig. MSC7401 Miniature sensor controller for inductive sensors Page 40...
  • Page 41 Appendix| Software The following window is displayed: Fig. 30 View Sensorfinder MSC7401 Miniature sensor controller for inductive sensors Page 41...

  • Page 42: A 3.2 Measurement

    Appendix| Software A 3.2 Measurement To check your measurements, a simple depiction of your data acquisition is available, see Fig. Fig. 31 View Measurement MSC7401 Miniature sensor controller for inductive sensors Page 42...

  • Page 43: A 3.2.1 Basic View

    Start the data acquisition by clicking the Start button, see Fig. The recording is completely restarted and the previously stopped recording is lost. Stop the data acquisition by clicking the Stop button, see Fig. Fig. 33 Start Fig. 34 Stop MSC7401 Miniature sensor controller for inductive sensors Page 43...

  • Page 44: A 3.2.3 Signal Processing

    Reset Resets the master. For the Master, please also note the table, see Fig. 1) For example every 5000 ms: The signal course displayed is updated after this period has elapsed. MSC7401 Miniature sensor controller for inductive sensors Page 44...

  • Page 45: Csv Output

    Click this button to save the currently selected measurement value. Click this button to cancel the recording. Data acquisition CSV output Format point / comma Separator comma / semicolon / tabulator / space Master Master now / Reset MSC7401 Miniature sensor controller for inductive sensors Page 45...
  • Page 46 When the Master tab is activated in the menu Data acquisition > Signal process- Mastering ing, see Fig. 35, you can enter the values manually under Current value after activating the Mastering checkbox. Fig. 38 Depiction and description of data acquisition table MSC7401 Miniature sensor controller for inductive sensors Page 46...

  • Page 47: A 3.3 Settings

    Appendix| Software A 3.3 Settings A 3.3.1 General Fig. 39 View Settings General MSC7401 Miniature sensor controller for inductive sensors Page 47...
  • Page 48 If the values are not correct, carry out the automatic sensor recognition manually or select the sensor model in the drop down menu. If the model is not listed, please contact Micro-Epsilon. Please note that changing the sensor model overwrites all manually set parameters.

  • Page 49: Output

    In order to achieve an optimal resolution, it is recommended to reduce the frequency response as much as possible. Please note that a reduced frequency response also involves a reduced measurement dynamic. MSC7401 Miniature sensor controller for inductive sensors Page 49...

  • Page 50: A 3.3.3 Adjustment

    Start the sensor adjustment via the Start button. Then move the target to the desired position X Enter the corresponding output value. Click Accept X MSC7401 Miniature sensor controller for inductive sensors Page 50...
  • Page 51 Appendix| Software Fig. 43 View 2 Two Point Adjustment Repeat this process for the second position X MSC7401 Miniature sensor controller for inductive sensors Page 51...
  • Page 52 Custom. The chart is divided into 3 areas: Green Taught-in range, limited by X and the associated output signals White Usable range outside the taught-in range Unavailable range MSC7401 Miniature sensor controller for inductive sensors Page 52...

  • Page 53: A 3.3.3.2 Zero Point

    Then move the target to the zero point X (target position = 0 %). Enter the desired output value for the midrange and accept it by clicking the button Accept X MSC7401 Miniature sensor controller for inductive sensors Page 53...
  • Page 54 Fig. 46 View 2 Zero Point adjustment Now move the target inside the midrange to the point X Also enter the desired output value there and accept it by pressing the button Accept X MSC7401 Miniature sensor controller for inductive sensors Page 54...
  • Page 55 Custom . The chart is divided into 3 areas: Green Taught-in range, limited by X and associated output signals. White Usable range outside the taught-in range Unavailable range MSC7401 Miniature sensor controller for inductive sensors Page 55...

  • Page 56: A 3.4 Info

    By clicking the Disconnect button you return to the sensor search. Clicking the Copy to Clipboard button copies the information and settings for the selected controller to the clipboard. MSC7401 Miniature sensor controller for inductive sensors Page 56...
  • Page 57 Fig. 51 Button Export Settings Fig. 52 Button Import Settings Clicking Import Settings opens the explorer and enables you to import the setting values from a default *.csv file onto the PC. MSC7401 Miniature sensor controller for inductive sensors Page 57...
  • Page 58 MICRO-EPSILON MESSTECHNIK GmbH & Co. KG X9751377-A021118HDR Königbacher Str. 15 · 94496 Ortenburg / Germany MICRO-EPSILON MESSTECHNIK Tel. +49 (0) 8542 / 168-0 · Fax +49 (0) 8542 / 168-90 *X9751377-A02* info@micro-epsilon.de · www.micro-epsilon.com...
