Sensor Parameters - MICRO-EPSILON induSENSOR DTD Operating Instructions Manual

Operation
5.3.3
LED D2 = red flashing
With this function, you can set the parameters
- sensor type,
- supply frequency and
- excitation voltage
if the automatic recognition is not successful, or for special areas of use other settings may be necessary.
These depend on the sensor model used. After manual setting of the sensor parameters, the adjustment of
the
Sensor model
DTA-1x
DTA-3x
DTA-5x
DTA-10x
DTA-15x
DTA-25x
LDR-10
LDR-25
LDR-50
LVP-3
LDR-14
LVP-25
Fig. 53 Sensor models and sensor parameters
induSENSOR DTD / MSC7xxx

Sensor Parameters

system, see 5.3.4, is recommended.
With 8 mm drawbar
With 10 mm drawbar
With 8 mm drawbar
With 10 mm drawbar
Measuring Sensor
range type
±1 mm
±3 mm
±5 mm
LVDT
±10 mm
±15 mm
±25 mm
10 mm
25 mm
50 mm
3 mm
LDR
14 mm
25 mm
Supply frequen-
Excitation voltage
cy
5 kHz
5 kHz
5 kHz
2 kHz
1 kHz
1 kHz
21 kHz
550 mV
13 kHz
9 kHz
18 kHz
23 kHz
23 kHz
16 kHz
16 kHz
Page 51
