Fig. 82 Signal processing
You can select the following options for signal processing:
Measurement
Fields with gray
background re-
quire a selection.
Fields with dark
1) For example every 5000 ms: The signal course displayed is updated after this period has elapsed.
border require
entry of a value.
induSENSOR DTD / MSC7xxx

Signal Processing

Signal processing Subsample Disabled
Sample-based
Time-based
Trigger Disabled
Continuous
One-shot
(sample-based)
One-shot
(time-based)
Master Master now
Reset
Deactivated; basic settings
Number of samples is adjustable,
every xth measurement is recorded.
Time-based; time can be set in
milliseconds
1
Deactivated; basic settings
Manual trigger
Sample can be set; records the
signal course according to the set
samples; the more samples, the
longer the course
Milliseconds can be set; records the
signal course according to the time
set
Sets the master, see Fig. 84.
Resets the master
