Appendix | Software
Sensor setup
Three options for sensor configuration:
- Automatic sensor
- Model setting
- User-specific sensor setting
i
Sensor recognition
After switching on, the controller automatically identifies the sensor.
After successful recognition, the sensor model, the associated excitation frequency and the excitation voltage
are automatically set.
Fields with gray
If the values are not correct, carry out the automatic sensor recognition manually or select the sensor model
background re-
in the drop down menu.
quire a selection.
i
Fields with dark
border require
entry of a value.
induSENSOR DTD / MSC7xxx
Sensor model
Excitation frequency
(Hz)
Excitation voltage (mV) 550 / 350 / 150 / 75
recognition, see 5.3.1
Please note that automatic sensor recognition is merely a support feature. Successful recognition can-
not be guaranteed on account of tolerances. As such, the recognition result must always be checked.
Check the values based on the operating
If the sensor model is not listed in the drop down menu, please contact Micro-Epsilon.
Please note that changing the sensor model overwrites all manually set parameters.
1 - 6: DTA-xD oder 7 - 10: DTA-xG8
127: user defined DTA
129 - 131, 133: LDR-x
132: LVP-25
255: user defined LDR
0: unknown sensor
Automatic recognition of sensor model
1000 / 2000 / 5000 / 8000 / 9000 / 10000 /
12000 / 13000 / 16000 / 18000 / 21000 / 23000 /
25000
instructions, see 5.3.3.
Only with
user-defined
sensor setting
