Install DIMMs
b. Carefully lift the DIMM straight up to remove it from the socket.
Callout
1
2
3
4. Replace each faulty DIMM with either another DIMM of the same rank size.
For DIMM replacement instructions, see
Caution -
must replace it before starting the server.
Install DIMMs
1. Unpack the replacement DIMMs and place them on an antistatic mat.
2. Ensure that the replacement DIMMs match the system requirements.
The system supports only 1333 MHz or 1600 MHz DDR3, 8GB, dual rank DIMMs obtained
from Oracle.
68 Oracle Database Appliance Service Manual • February 2016
Description
DIMM connector slot
DIMM connector key
DIMM ejector lever
Do not operate the system with an empty DIMM slot. If you remove a DIMM, you
"Install DIMMs" on page 68.
