6. In the dialog box, do one of the following:
■
Select -Enabled to enable the Option ROM setting.
■
Select -Disabled to disable the Option ROM setting.
Press F10 to save the changes and exit the BIOS Setup Utility.
7.

BIOS Setup Utility Hot Keys

The following table provides a description of the Oracle Database Appliance (original version)
BIOS Setup Utility Oracle ILOM Remote Console keys and the directly attached keyboard
keys, and the corresponding serial connection key combinations.
Oracle ILOM Remote Console Keys
F1
F2
F7
F8
F9
†
F10
F12
†
F10 is not supported on the Oracle ILOM Remote Console; instead, use the arrow keys to navigate to the Exit menu and press Enter.

Accessing the BIOS Setup Utility Menus

You can access Oracle Database Appliance (original version) BIOS Setup Utility screens from
the following interfaces:
Use a USB keyboard, mouse, and VGA monitor connected directly to the server node.
■
Use a terminal (or terminal emulator connected to a computer) through the serial port on the
■
back panel of the server node.
Serial Connection Hot Key
Combinations
Ctrl+Q (Press and hold the Control
key and type Q)
Ctrl+E
Ctrl+D
Ctrl+P
Ctrl+O
Ctrl+S
Ctrl+N
Chapter 8 • Server Node Basic Input/Output System (BIOS)
Enable or Disable Option ROM Settings
Function
Access the BIOS Setup Utility if
there is an error during the boot
process.
Enter BIOS Setup Utility when the
system has completed the power-on
self-test (POST).
Discard changes, but do not exit.
Select the BBS Popup menu, which
allows you to select a boot device.
Load optimal BIOS defaults.
Save changes and exit.
Boot the server node from the
network (PXE boot).
167
