Using your thumb and forefinger, squeeze the release button [1] toward the lever

hole to release the lever [2].

Grasp the lever and remove the I/O module.

Caution -

I/O module.

Open the lever in the new I/O module if it is not already open.

Slide the new I/O module into the disk shelf.

Reconnect the cables.

Verify that the new I/O module is working correctly.

After approximately 60 seconds, the power LED should be solid green and the Fault/Locate

■

LED should be off.

For each port that has a cable connected, all four activity LEDs should be solid green.

■

Oracle Database Appliance (Original Version) Hot-

Swappable Components

This section describes replacing hot-swappable components for the Oracle Database Appliance

(original version) for service. If you have Oracle Database Appliance X3-2, Oracle Database

Oracle Database Appliance (Original Version) Hot-Swappable Components

Equipment damage. Be careful not to damage the connector pins at the back of the

Chapter 3 • Servicing CRUs That Do Not Require System Power Off
