Install A Boot Drive - Oracle Database Appliance Service Manual

b. Pull the door open [2].
On the drive you plan to remove, push the storage drive release button to
c.
open the latch [2].
Grasp the latch and open it to a 45 degree angle [2].
d.
e. Using the latch, slowly pull the drive straight out of the drive slot, not
sideways or vertically [2].
Do not use much force on the latch when removing the drive.
Equipment damage. Do not use the latch as an ejector. Do not bend it too far to the
Caution -
right.
Equipment damage. Close the door after removing a boot drive to prevent
Caution -
overheating due to improper airflow.

Install a Boot Drive

Determine the drive slot location for the replacement drive.
1.
Chapter 3 • Servicing CRUs That Do Not Require System Power Off
Install a Boot Drive
53
