Oracle Database Appliance (Original Version) Status
Indicators
This section describes the status indicators for the original version Oracle Database Appliance.
"Server Node Status Indicators" on page 17
■
"Server Node Fan Indicators" on page 20
■
"Storage and Boot Drive Status Indicators" on page 21
■
"Power Supply Status Indicators" on page 21
■
"Rear Server Node Status Indicators" on page 22
■
"Server Node Internal LEDs" on page 24
■
"Ethernet Port Indicators" on page 25
■

Server Node Status Indicators

The following table lists and describes the general status indicators on the front and rear panel
of each Oracle Database Appliance (original version) server node.
Indicator/LED: Color
Power supply status indicator:
green
Fan fail indicator: amber
DC power fail indicator: amber
SAS I/O Module status
indicators: green or amber
Reserved
Network port (reserved)
Host SAS port activity indicators
(x4 per port): green

Oracle Database Appliance (Original Version) Status Indicators

State Meaning
■ On – The power supply is operating normally.
■ Off – The power supply is unplugged or turned off.
■ On – The fan is faulty.
■ Off – Normal operation.
■ On – The power supply is faulty.
■ Off – Normal operation.
■ OK – Lights green to indicate normal operation.
■ Service Required – Lights amber to indicate a fault with the I/O
module (top module is 0; bottom module is 1).
This port is reserved for Oracle Service.
This port is reserved for Oracle Service.
Lights green to indicate host SAS link activity.
