Memory modules (DIMMS)
■
See "Install DIMMs" on page
PCIe riser and attached PCIe cards
■
See "Install PCIe Riser in Server Nodes" on page
CPUs
■
See "Install Processor (CPU)" on page
Internal PCIe card
■
See "Install Primary HBA PCIe Card in Motherboard" on page
3. Reconnect and install the following cables.
Fan module power cables.
■
See "Servicing the Fan Power Cables (FRU)" on page
Internal PCIe card data cables.
■
See "Servicing the PCIe Card Cables (FRU)" on page
Equipment damage. The disk drive data cables are delicate. Handle them carefully.
Caution -
Boot disk backplane cables.
■
See "Servicing the Boot Disk Backplane Cables (FRU)" on page
4. Return the server node to operation.
a. Install the server node top cover.
See "Installing the Server Node Top Cover" on page
Install the server node into the system.
b.
See "Installing a Server Node Into the System Chassis" on page
c. Reconnect all external data cables from the PCIe card(s) that are installed in
the PCIe riser.
Power on the server node.
d.
See "Powering On Oracle Database Appliance (Original Version)" on page
Install Replaceable Components in Motherboard Assembly
68.
74.
100.
124.
139.
81.
122.
130.
140.
142.
