Storage Shelf Status Indicators - Oracle Database Appliance Service Manual

Oracle Database Appliance X5-2 Status Indicators
Note -
the Oracle Server X5-2 documentation library. Use your browser's Back button to return to the
Oracle Database Appliance library.
Server Node General Status Indicators
■
Server Node Fan Status Indicators
■
Server Node Storage Drive Status Indicators
■
Server Node Power Supply Status Indicators
■
Server Node Motherboard Status Indicators
■

Storage Shelf Status Indicators

Storage shelves are supported with Oracle Database Appliance X5-2. They include controls and
indicators on the front panel, hard drives, SSD drives, power supplies, and SAS I/O modules.
Storage Shelf Front Panel and Drive Indicators
The following figure shows the controls and indicators on the storage shelf front panel and
drives.
12 Oracle Database Appliance Service Manual • February 2016
The links below take you to topics outside of the Oracle Database Appliance library to
