6. Reinstall both server nodes into the system.
See "Installing a Server Node Into the System Chassis" on page
7. Return the system to operation.
a. Install both power supplies into the system.
See "Install a Power Supply" on page
b. If the system was installed in a rack, reinstall it into the rack.
See the Oracle Database Appliance Owner's Guide for instructions.
c. Reconnect the power cords to the system and power on the system.
See "Powering On Oracle Database Appliance (Original Version)" on page
Servicing the Disk Midplane Module HDD Cable
(FRU)
The Oracle Database Appliance (original version) HDD cable connects the power distribution
board to the disk midplane module.
The disk midplane module HDD cable is a FRU and can only be replaced by an Oracle-
qualified service technician.
Equipment damage. Remove all power from the system before removing or
Caution -
installing the disk midplane module HDD cable. Power down both server nodes (also called
system controllers) and disconnect the power cords from the system before performing
these procedures. For instructions, see
System" on page 31.
The following topics are covered in this section:
"Remove Disk Midplane Module HDD Cable" on page 115
■
"Install Disk Midplane Module HDD Cable" on page 116
■
Remove Disk Midplane Module HDD Cable
1. Prepare the system for service.
a. Power off the system.
Remove Disk Midplane Module HDD Cable
59.
"Shutting Down a Server Node and Powering Off the
140.
142.
Chapter 5 • Servicing FRUs 115
