Remove Boot Disk Backplane Cables
c. Install the server node into the system.
See
Power on the server node.
d.
See
Servicing the Boot Disk Backplane Cables (FRU)
The Oracle Database Appliance (original version) boot disk backplane cables connect the boot
disk backplane to the motherboard.
The boot disk backplane cables are FRUs and can only be replaced by an Oracle-qualified
service technician.
The following topics are covered in this section:
"Remove Boot Disk Backplane Cables" on page 130
■
"Install Boot Disk Backplane Cables" on page 131
■
Remove Boot Disk Backplane Cables
Prepare the server node for service.
1.
a. Attach an antistatic wrist strap.
See
Remove the server node from the system.
b.
Power is removed from the server node when you remove it from the system. See
"Removing Server Nodes From the System Chassis" on page
c. Remove the server node top cover.
See
2. Disconnect the power cable and hard disk drive (HDD) cables and remove them
from the server node.
Disconnect the power cable and HDD cables from the motherboard [1].
a.
130 Oracle Database Appliance Service Manual • February 2016
"Installing a Server Node Into the System Chassis" on page
"Powering On Oracle Database Appliance (Original Version)" on page
"Performing Electrostatic Discharge and Antistatic Prevention Measures" on page
"Removing the Server Node Top Cover" on page
140.
142.
34.
35.
34.
